Load meets or exceeds the following standards: ASTM E4, ISO7500-1, EN 10002-2, BS1610, DIN 51221.
Strain measurement meets or exceeds the following standards: ASTM E83, ISO 9513, BS 3846 and EN 10002-4
|
Model
|
HTT-500
|
HTT-1000
|
HTT-2000
|
HTT-5000
|
HTT-10000
|
HTT-15000
|
|
Max. testing load(kN)
|
500
|
1000
|
2000
|
5000
|
10000
|
15000
|
|
Amplifying multiple
|
1,2,5(Three steps)
|
|
Accuracy of specimen elongation
|
1% of F.S.
|
|
Test load accuracy
|
Better than 1% of indicating value
|
|
Displacement resolution (mm)
|
0.02
|
|
Tensile testing space(mm)
|
500 1000 2000
|
500 1000 3000
|
500 1000 3000
|
500 1000 3000
|
1000 3000 5000
|
2000 5000 8000
|
|
Ram stroke(mm)
|
300 500 1000
|
300 500 1000
|
300 500 1000
|
300 500 1200
|
500 800 1500
|
600 1000 2000
|
1. Data Acquisition Rate:
Generally, data acquisition rate is up to 50 Hz synchronous on load and strain by TE controller & software. Customized data acquisition rate is up to 1 kHz synchronous on load and strain by EDC220 controller.
2. Load Measurement Accuracy:
±0.5 % or ±1 % from range of 1% to 100% FS
3. Strain Measurement Accuracy:
Meets or surpasses the following standards ASTM E83, ISO 9513, BS 3846 and EN 10002-4.
4. Position Measurement Accuracy:
Standard encoder: 1 µm resolution, position accuracy of ±1% displacement.
5. Hydraulic Power Supply Voltage:
3 phases, 380VAC, 50Hz
6. Other Specifications Upon Request
