Model |
MRC-30 |
MRC-50 |
MRC-100 |
Max. Load |
30kN |
50kN |
100kN |
Effective measuring range |
2%~100%FS |
Relative error of the load display |
≤ ±1% |
Load resolution |
±1% |
Min. dead weight |
1N |
Automatic leveling |
±0.1 mm |
Lever ration |
1:50 |
1:60 |
Lower chuck speed |
0-50mm/min |
Chuck speed accuracy |
±0.5% |
Chuck travel |
0~150mm |
0~200mm |
Chuck ment |
≤10% |
Standard Size of specimen |
Creep test: φ10x100mm; Rupture strength test: φ10x50mm; Different adaptors can be provided per the required standards; |
Load frame dimension |
930x660x2370mm |
1150x720x2660mm |
Column clearance |
490mm |
480mm |
Column diameter |
φ60mm |
φ70mm |
Load frame weight |
Approx.1050kg |
Approx.1350kg |
Deformation timing |
Above 7000hrs |
Timing error |
±0.1% |
High temperature furnace & Temperature-controller |
Temperature range |
200-900°C/200-1100°C /200-1200°C |
Length of effective soaking zone |
Min. 100mm(Max.300mm) |
Furnace pipe & electric furnace size: |
Furnace inner chamber: φ90mm×380mm (L), Furnace outside: φ300mm ×420mm (L) |
Furnace shell temperature |
≤90°C |
Temperature-controller |
SHIMADEN, Japan with Sensitivity of 0.1°C |
Thermal couple |
K type, 3 pcs |
Deformation measuring |
By LVDT Heidenhain from Germany |
Max. deformation |
5mm or 10mm |
Deformation accuracy |
±1um |
Deformation resolution |
1um |
Power |
Load frame 220V±10%, 50Hz Furnace 380V±10%; 50Hz±2%, 3KW |
