Applied Standards
ASTM D-2266, D-3702, D-4172, ASTM G99
Features
● The machine adopts process control principle, and combines industrial control computer with the configuration software technology and internet technology;
● Apply incorporate structure design, integrate embedded industry computer, configuration software, acquisition module and executor as a whole to control the test process, all test operations can be completed at the main interface of the computer;
● It features flexible configuration control mode, multiple friction couplings, wide speed adjusting range, simulating high temperature circumstances, and high automation.
Specifications
|
Load range (N)
|
10 - 1000 (Stepless)
|
|
Relative Error of Load Indicating Value (% )
|
±1
|
|
Friction Torque Measuring Range (N.m)
|
2.5
|
|
Relative Error of Friction Torque Indicating (%)
|
±2
|
|
Rotate Speed Range of Spindle (r/min )
|
1 - 2000r/min, linear velocity up to over 4 m/s.
|
|
|
when use decelerating device: 0.05 - 20
|
|
Test Medium
|
oil, water, slurry, abrasive etc.
|
|
Temperature Control Range (℃)
|
From room temperature to 200
|
|
Max. Distance between Spindle of the Machine and Lower Friction Coupling Pate (mm )
|
>75
|
|
Time Control Range
|
10s to 9999min
|
|
Computer & Data Processing Range
|
It applies industrial control computer and configuration software to control the machine and test process, display different parameters in real time, and to record friction-time curve and temperature-time curve automatically. Control: load, time, temperature, test duration. Curves: Temperature-Time, Friction- torque and Time etc. Data can be printed by Excel.
|
|
Power Supply
|
1 phase, 220V, 50Hz.
|
|
Dimension (mm)
|
900 × 760 × 1600
|
|
Weight (kg)
|
800
|
|
|
|
Heating Device
|
Load Cell
|
Industrial Computer and Software
|
|
|
|
|
|
Four Ball
|
Ring On Block
|
Pin On Disc
|
Pin On Tri-Pole(Option)
|
Ball On 3-Pole(Option)
|
